Product Description Of HMC8038LP4CETR
HMC8038LP4CETR is a high isolation, nonreflective, 0.1 GHz to 6.0 GHz, silicon, single-pole, double-throw (SPDT) switch in a leadless, surface-mount package. The switch is ideal for cellular infrastructure applications, yielding up to 62 dB of isolation up to 4.0 GHz, a low 0.8 dB of insertion loss up to 4.0 GHz, and 60 dBm of input third-order intercept. Power handling is excellent up to 6.0 GHz, and it offers an input power for an 0.1 dB compression point (P0.1dB) of 35 dBm (VDD = 5 V). On-chip circuitry operates a single, positive supply voltage from 3.3 V to 5 V, as well as a single, positive voltage control from 0 V to 1.8 V/3.3 V/5.0 V at very low dc currents. An enable input (EN) set to logic high places the switch in an all off state, in which RFC is reflective.

Specifications Of HMC8038LP4CETR

Features Of HMC8038LP4CETR
Nonreflective, 50 Ω design
High isolation: 60 dB typical
Low insertion loss: 0.8 dB typical
High power handling
34 dBm through path
29 dBm terminated path
High linearity
0.1 dB compression (P0.1dB): 35 dBm typical
Input third-order intercept (IP3): 60 dBm typical
ESD ratings
4 kV human body model (HBM), Class 3A
1.25 kV charged device model (CDM)
Single positive supply
3.3 V to 5 V
1.8 V-compatible control

Applications Of HMC8038LP4CETR
Cellular/4G infrastructure
Wireless infrastructure
Automotive telematics
Mobile radios
Test equipment
