SI5338A-B-GM Integrated Circuit Chip 710MHz Low Jitter Clock Generator IC QFN24

SI5338A-B-GM Integrated Circuit Chip 710MHz Low Jitter Clock Generator IC QFN24

Product Description Of SI5338A-B-GM

SI5338A-B-GM is a high-performance, low-jitter clock generator capable of synthesizing any frequency on each of the device's four output drivers.
SI5338A-B-GM allows generation of four independent clocks with 0 ppm precision. Each output clock is independently configurable to support various signal formats and supply voltages.
SI5338A-B-GM provides low-jitter frequency synthesis in a space-saving 4 x 4 mm QFN package. The device is programmable via an I2C/SMBus-compatible serial interface and supports operation from a 1.8, 2.5, or 3.3 V core supply.

Specification Of SI5338A-B-GM

Features Of SI5338A-B-GM

Low power MultiSynth™ technology enables independent, any-frequency synthesis on four differential output drivers
PCIe Gen 1/2/3/4 Common Clock and Gen 3 SRNS compliant
Highly-configurable output drivers with up to four differential outputs, eight single-ended clock outputs, or a combination of both
Low phase jitter of 0.7 ps RMS typ
High precision synthesis allows true zero ppm frequency accuracy on all outputs
Flexible input reference:
External crystal: 8 to 30 MHz
CMOS input: 5 to 200 MHz
SSTL/HSTL input: 5 to 350 MHz
Differential input: 5 to 710 MHz
Independently configurable outputs support any frequency or format:
LVPECL/LVDS: 0.16 to 710 MHz
HCSL: 0.16 to 250 MHz
CMOS: 0.16 to 200 MHz
SSTL/HSTL: 0.16 to 350 MHz
Independent output voltage per driver: 1.5, 1.8, 2.5, or 3.3 V
Single supply core with excellent PSRR: 1.8, 2.5, 3.3 V
Independent frequency increment/decrement feature enables glitchless frequency adjustments in 1 ppm steps
Independent phase adjustment on each of the output drivers with an accuracy of <20 ps steps
Highly configurable spread spectrum (SSC) on any output:
Any frequency from 5 to 350 MHz
Any spread from 0.5 to 5.0%
Any modulation rate from 33 to 63 kHz
External feedback mode allows zero-delay mode
Loss of lock and loss of signal alarms
I2C/SMBus compatible interface
Easy to use programming software
Small size: 4 x 4 mm, 24-QFN
Low power: 45 mA core supply typ
Wide temperature range: –40 to +85 °C

Applications Of SI5338A-B-GM
Ethernet switch/router
PCIe Gen1/2/3/4
Broadcast video/audio timing
Processor and FPGA clocking
Any-frequency clock conversion
MSAN/DSLAM/PON
Fibre Channel, SAN
Telecom line cards
1 GbE and 10 GbE
