MP9447GL Integrated Circuit Chip 5A 36V Synchronous Step-Down Converter QFN-20

MP9447GL Integrated Circuit Chip 5A 36V Synchronous Step-Down Converter QFN-20​

Product Description Of MP9447GL

MP9447GL is a fully-integrated, high-frequency, synchronous, rectified, step-down, switch-mode converter. It offers a very compact solution to achieve a 5A, continuous-output current over a wide input-supply range with excellent load and line regulation. It also provides fast transient response and good stability for wide input-supply and load range.

Specification Of MP9447GL

Features Of MP9447GL

Wide 4.5V-to-36V Operating InputRange
Guaranteed 5A, Continuous Output Current
Internal 65mΩ High-Side, 30mΩ Low-Side Power MOSFETs
Proprietary Switching-Loss-Reduction Technology
1.5% Reference Voltage
Programmable Soft-Start Time
Low Drop-out Mode
200kHz-to-650kHz Switching Frequency
SCP, OCP, UVP, and Thermal Shutdown
Output Adjustable from 0.8V to 0.9×VIN
Available in a 3×4mm 25-pin QFN Package

Applications Of MP9447GL

General Consumer
USB Power Supplies
Cigarette Lighter Adapters
Power Supply for Chargers
