LMR23630APDRRR Integrated Circuit Chip 36V Input 3A Output 400kHz Synchronous Step-Down Converter

LMR23630APDRRR SIMPLE SWITCHER is an easy-to-use 36 V, 3 A synchronous step-down regulator. With a wide input range from 4 V to 36 V, it is suitable for various industrial applications for power conditioning from unregulated sources. Peak-current-mode control is employed to achieve simple control-loop compensation and cycle-by-cycle current limiting.

A quiescent current of 75 µA makes the device suitable for battery-powered systems. An ultra-low 2 µA shutdown current can further prolong battery life. Internal loop compensation means that the user is free from the tedious task of loop compensation design. This also minimizes the external components.

• 4-V to 36-V Input range
• 3-A Continuous output current
• Integrated synchronous rectification
• Current-mode control
• Minimum switch on-time: 60 ns
• Internal compensation for ease of use
• 400-kHz Switching frequency and adjustable frequency options
• PFM and forced PWM mode options
• Frequency synchronization to external clock
• 75-µA Quiescent current at no load for PFM option
• Soft start into a prebiased load
• High duty-cycle operation supported
• Precision enable input
• Output short-circuit protection with hiccup mode
• Thermal protection
• 8-Pin HSOIC with PowerPAD™ package
• 12-Pin WSON wettable flanks package with PowerPAD™
• Use the LMZM33603 module for faster time to market

• Factory and building automation systems: PLC CPU, HVAC control, elevator control
• Asset tracking
• General purpose wide VIN regulation
